Bar-drivers, introduced in 1988 for the Sealine 365 and 328 models, providing a bar-graph read out for the mains battery charger output amps.

In 1990 we introduced a new display with a digital voltage read-out, plus a bar-graph for service net amps. This employed a sensor that measured the magnetic field around the supply cable. Driving two bar graphs, red for discharge, green for charge.

In 1991 the next development saw a 30 dot bar graph, again showing red and green dots for net service amps. This bar-driver featured a through stud, and was now fitted in the starter motor / service load supply cable. This year also saw the introduction of AC bar-drivers, again using the magnetic senor head.

!998 saw the next big development, a solid state shunt for analogue gauges. This was a development of the bar-driver, using the same magnetic sensing system, and driving two different value meters from the same module. These units were fitted to most Sealine models from around 1999 to date.

new replacement bar-drivers and shunts

A range of replacement modules covering all units supplied from 1988 on.

These cover all shunts and bar-drivers, both DC and AC. They are normally plug compatible with the original unit, and are operationally inter-changeable.

Is my bar–driver or shunt faulty?

If you think it may not be working, but not sure, please phone us. Yes even if it’s a 1988 unit, we are happy to explain how to check if you have a fault. Or if the bar-driver shunt, is OK, were the fault actually lies.

If still in doubt, please return the relay, and we will test it for you.

If in doubt please ask

230

240

260

270

290

300

310

320

328

330

350

360

365

380

390

400

410

420

450

all boats 1998 on

Marine Projects

B4, B4/2

B4/1

B4, B4/2

B3, B4

BR1, B2, B3

B4/2

B4/1

B4/2

BR1, B2. B3

B4/1

B4/6

B4 generator

B4/6 service

AB1/1,AB2/1

AB1/1

AB1, AB1/1

AB2, AB2/1

Sealine model

DC bar-driver

AC bar-driver

buy now

Ordering check your boat model on the chart, click ‘buy now’ to enter the shop, mouse over your bar-driver on the LH side for detail of the application.

Select bar-driver / shunt and click add to basket.
